Beckhoff EL7211 EtherCAT Terminal

• Connection method direct motor connection + feedback
• Number of inputs 1 x feedback
• Load type permanent magnet-excited three-phase synchronous motor
• Number of channels 1
• Number of outputs 1 x servomotor, 1 x motor brake
• Supply voltage electronics 24 V DC (via power contacts)
• Supply voltage power 8…48 V DC (external)
• Output current (rms) 4.5 A
• Peak current (rms) max. 9.0 A for 1 s
• Performance increase –
• Rotating field frequency 0…599 Hz
• PWM clock frequency 16 kHz
• Current controller frequency 32 kHz
• Rated speed controller frequency 16 kHz
• Output voltage motor brake 24 V DC

The EL7211 servomotor EtherCAT Terminal with integrated resolver interface offers high servo performance in a very compact design for motors from the AM8100 and AM3100 series up to 4.5 A (Irms). The fast control technology, based on field-orientated current and PI speed control, supports fast and highly dynamic positioning tasks.

Monitoring of numerous parameters, such as overvoltage and undervoltage, overcurrent, terminal temperature or motor load via the calculation of a I²T model, offers maximum operational reliability. EtherCAT, as a high-performance system communication, and CAN-over-EtherCAT (CoE), as the application layer, enable ideal interfacing with PC-based control technology. The latest power semiconductors guarantee minimum power loss and enable feedback into the DC link when braking. 16 LEDs indicate status, warning and error messages as well as possibly active limitations.
